DotMatrix Graphic LCD Screens from Shenzhen Hengxunchuang Technical Specifications Global Compliance

This technical article provides a comprehensive overview of dot-matrix graphic LCD screens developed by Shenzhen Hengxunchuang Technology Co.,LTD., a leading industrial display supplier with 13 years of R&D experience. Our screens are designed for industrial controller designers, instrument manufacturers, and medical device developers, solving pain points like inflexible fixed-character displays, high legacy component replacement costs, and compatibility issues. Adhering to ISO 9001, CE, and RoHS standards, our products feature full-dot-matrix drive architecture and seamless microcontroller compatibility. They have been applied in 10+ countries, serving hundreds of clients in industrial automation, power instrumentation, and medical equipment, with CE, FCC, and RoHS certifications for global reliability .

Technical Definition & Classification

Dot-matrix graphic LCD screens are full-dot-matrix drive components supporting custom patterns, icons, and mixed text-graphics display, built on STN/FSTN/FFSTN monochrome technologies. As a core industrial display component, it enables flexible visual output for automation and equipment modernization . Our product line includes two main series: Standard Resolution Series (122×32 to 320×240, cost-effective for general use) and Wide-Temperature Industrial Series (-20℃~+70℃, customizable to -40℃~+85℃, for harsh environments) . We follow a design philosophy of high reliability, easy integration, and long lifespan to meet industrial site demands .

Technical Principle & Core Advantages

Our screens operate on full-dot-matrix drive architecture with a built-in control chip, converting host controller signals to precise pixel control for flexible display output. Compared to traditional fixed-character screens, our products offer two key verified advantages: 1. Flexible Custom Display: Eliminates fixed-output limitations, supporting custom graphics and mixed content to meet diverse visual needs . 2. Legacy Compatibility: Directly works with old industrial controllers, reducing replacement costs and integration complexity by up to 60% . Additionally, our industrial-grade construction ensures anti-electromagnetic interference and 50,000+ hour backlight lifespan, maintaining stable performance in field and industrial settings .

Key Technical Parameters

All parameters meet ISO 9001 standards, with clear test conditions and strict tolerance control. Key specifications include:

Parameter	Standard Value	Selection Guidance
Resolution Range	122×32 to 320×240	Match with content complexity requirements
Operating Temperature	-20℃~+70℃ (customizable to -40℃~+85℃)	Select based on working environment conditions
Supported Interfaces	SPI, I2C, RGB, MCU	Align with host controller interface type
Backlight Lifespan	≥50000 hours	Ideal for long-term continuous operation scenarios

Customization is available for special working conditions or unique application needs .

International Compliance & Certifications

Our products follow ISO 9001, CE, and RoHS international standards, with a complete certification system to meet global market access requirements. Key certifications include ISO 9001 quality management system, CE safety certification, FCC electromagnetic compatibility certification, and RoHS hazardous substance compliance . We provide full technical documents such as product specification sheets, certification reports, and test records upon customer request to support regulatory compliance .

Typical Application Scenarios

1. Industrial Controller Maintenance: Our compatible replacement screens match original factory hardware and software standards, enabling plug-and-use installation without debugging, reducing equipment downtime by 70% compared to original spare parts procurement . 2. Power Instrumentation: Wide-temperature models with low-power drive optimization ensure stable operation in outdoor environments, achieving 5-year continuous use without backlight failure and reducing instrument maintenance costs .

Technical FAQ

Q: Can your dot-matrix graphic LCD screens be customized?
A: Yes, we offer full-process customization services including size, resolution, backlight, and interface adjustments to meet special application needs .
Q: What is the minimum order quantity for your products?
A: Standard models have no strict MOQ, while custom models require a minimum order of 100PCS, supporting small and medium batch orders .
Q: Do you provide technical support for product integration?
A: Our professional engineering team offers one-on-one model selection, installation guidance, and troubleshooting support throughout the integration process .
